BIAS TEES -
We offers a large variety of bias tees that cover frequencies from 30 KHz to 20 GHz in both surface mount and connectorized packages. Many models are available with voltages up to 50 volts and currents up to 5 amps and custom requirements are welcomed. Options include higher voltage and current, higher RF input power and a choice of either an RF connector or a feed through connection for the DC input port.
BIAS TEES 0.01 to 40 GHz
|
Frequency Range (MHz) |
Isolation (dB) min. |
Insertion Loss (dB) max. |
Current (mA) max.1 |
VSWR max. |
OUTLINE NUMBER |
|
50- |
25 |
0.6 |
6000 |
1.20:1 |
|
|
10- |
25 |
1.0 |
200 |
1.20:1 |
|
|
800- |
25 |
0.5 |
1000 |
1.20:1 |
|
|
1700- |
25 |
0.7 |
1000 |
1.20:1 |
|
|
500- |
25 |
1.0 |
200 |
1.20:1 |
|
|
10- |
25 |
1.8 |
3000 |
1.50:1 |
|
|
500- |
25 |
1.0 |
500 |
1.20:1 |
|
|
10- |
25 |
1.2 |
200 |
1.20:1 |
|
|
1000- |
35 |
1.0 |
1000 |
1.50:1 |
|
|
100- |
30 |
1.5 |
500 |
1.50:1 |
|
|
500- |
30 |
1.0 |
200 |
1.50:1 |
|
|
5000- |
30 |
0.8 |
250 |
1.50:1 |
|
|
10000- |
35 |
1.0 |
200 |
1.50:1 |
|
|
8000- |
35 |
1.0 |
200 |
1.50:1 |
|
|
300- |
25 |
1.5 |
500 |
1.60:1 |
|
DC BLOCK 0.01 TO 18 GHz
|
Frequency Range (GHz) |
Insertion Loss (DB) Max. |
Voltage (volts) max. |
VSWR max. |
OUTLINE NUMBER |
|
0.0001- |
0.5 |
50 |
1.20:1 |
DCB1 |
|
0.0001- |
0.6 |
100 |
1.25:1 |
DCB2 |
|
0.001- |
0.7 |
100 |
1.30:1 |
DCB3 |
|
6.0- |
0.5 |
100 |
1.35:1 |
DCB4 |
|
6.0- |
0.7 |
500 |
1.50:1 |
DCB5 |
|
0.3- |
0.5 |
50 |
1.30:1 |
DCB6 |
